PROline Prosonic Flow 93 PROFIBUS-DP/-PA
Endress+Hauser
Fig. 39:
Installing the dual path measuring sensors, step 13
14. Then screw the sensors into the sensor holders by hand. If you use a tool, the
maximum torque permissible is 30 Nm.
15. Insert the sensor cable plug into the opening provided and manually tighten the
plug to the stop.
Fig. 40:
Installing the dual path measuring sensors, step 14 and 15
3 Installation
35
