2-4 External and Mounting Dimensions
1,000-r/min Motors (400 V)
900 W (without Brake)
R88M-K90010F (-S2)
R88M-K90010C (-S2)
900 W (with Brake)
R88M-K90010F-B (S2)
R88M-K90010C-B (S2)
2
Motor and brake
connector
Encoder
connector
R88M-K90010x
R88M-K90010x-Bx
Note. The standard models have a straight shaft. Models with a key and tap are indicated with S2 at the
2-47
INC
ABS
INC
ABS
LL 70
LM
KB2
KB1
12 6
Model
LL
155.5
183.5
end of the model number.
Models with an oil seal are indicated with O at the end of the model number. The motor dimensions
do not change.
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
130×130
(Shaft end specifications with key and tap)
70
45
4-ø9
Dimensions (mm)
LM KB1 KB2
111.5 77.5 133.5
139.5 74.5 161.5
41 M3, through
8h9
M5 (depth 12)
