50 W/100 W (with Brake)
R88M-K05030H-B (S2)/-K10030L-B (S2)
R88M-K05030T-B (S2)/-K10030S-B (S2)
Encoder connector
Brake connector
LL
LM
Model
R88M-K05030x-Bx
R88M-K10030x-Bx
Note. The standard models have a straight shaft. Models with a key and tap are indicated with S2 at the
end of the model number.
Models with an oil seal are indicated with O at the end of the model number. The motor dimensions
do not change.
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
Motor connector
25
6 3
2
LN
1.5 min.
Boss insertion position
(only for the ones with oil seal)
Dimensions (mm)
LL LM
102 78
122 98
2-4 External and Mounting Dimensions
INC
ABS
40×40
(Shaft end specifications with key and tap)
R3.7
R4.2
2−φ4.3
LN
23
43
25
14
3h9
12.5
M3 (depth 6)
2-30
2
