4-3 Wiring Conforming to EMC Directives
External Dimensions
For single-phase (BWZ series) For 3-phase (BXZ series)
φ4.2 φ4.2
1 2 1 2 3
4
41 41
Equalizing Circuits
For 3-phase (BXZ series)
For single-phase (BWZ series)
(1) (2) (3)
(1) (2)
4-32
