Table 3-14: VoIP Participant Properties - Connection Info1 (Continued)
Field/Option
FECC Token
Content Token
Channel Info
If required, modify the following parameters:
disconnect the connected participant.
—
4. Click the Connection Info2 tab.
The Participant Properties - Connection Info2 dialog box opens.
MGC Manager User's Guide - VoicePlus Edition
Description
Not relevant in Audio Only.
Not relevant in Audio Only.
Displays detailed information about a selected channel.
You can click this button to expand (>>) or to collapse
(<<) the additional Channel Info pane.
In the Channel Status table Channel column, select a
channel to monitor and click this button.
Note: The displayed information varies according to the
properties of the selected channel.
3-41
