Table 3-11: ISDN Participant Properties - Resource Details (Continued)
Field/Option Description
Resource Type The type of the conference resource installed in the MCU:
•
•
•
•
•
•
•
Board ID The number of the slot where the card containing the
resource that is used to run the conference and handle
the participant, is installed.
Unit ID The unit number (on the card) used to handle the
participant in the conference.
Allocated Indicates whether the MCU resources listed in the
Resource Type column are allocated to the conference.
Connection ID The number identifying participant's connection.
Net Resources
Displays information about the network interface module used to run the
conference and handle the participant.
Channel The participant's channel number.
Board ID The number of the slot in which the card containing the
resource that is used to run the conference and handle
the participant, is installed.
Unit ID The span used to handle the participant in conference.
Port ID The port number on the Network card allocated to the
participant.
MGC Manager User's Guide - VoicePlus Edition
MUX - The MUX card. Not relevant to Audio Only
participant.
Audio Codec - The audio encoding /decoding port.
Audio Bridge - The Audio Bridge that mixes the audio
signal received from various ports. Applicable only to
Video participants using the Standard Audio card to
connect to the conference.
T120 Codec - Not relevant to Audio Only participant.
T120 Bridge - Not relevant to Audio Only participant.
Video - Not applicable to Audio Only.
IP - Applicable to H.323 and SIP participants.
3-35
