Feeder Line Assembly and Suspension

Installing Feeders on the Feeder Tube

Installing Cone Cap
1.Line up the Feeder with the hole in the Feeder Tube (Item 1)
2.Konavi- Set a Konavi Cone Cap (Item 2) on the Feeder Tube, and Slide it past the Locking Tabs so it locks
into place as shown.
1
20
Hole in Feeder Tube
Item Description
1 Feeder Tube
2 Konavi Cone Cap
Figure 18.Feeder Installation
Konavi® Pullet Feeding System
Part No.
--
56753
2
MF2514A
