Item Part No.
1 56576 Control Sensor Body
2 56579 Support Tube Assembly
3 48081 Center Divider
4 48086 End Control Bottom Cover
5 4416-7 10-24 Hex Screw
6 6956 Box Mounting Cover
7 34019 10-24 Nylon Hx Lock Nut
8 28075 #10 x.5 Screw
9 6777 Switch Box Gasket
10 52316-2 Control Panel Relay Mount
11 35493 4-24 x /375 Phil PH Screw
12 28904
13 34660 6-32 x .375 SFTP Screw
14 42627-12 General Purpose Box
15 26980 Liquid Tight Fitting
16 43662 .50 Conduit Lock Nut
17 24685 Water Tight Connector
18 23779 Liquid Tight Connector
19 6776 Terminal Box Cover
20 2526-377 Date of Manufacture Decal
21 57430 Konavi Breeder Cone
22 56753 Konavi Breeder Cap
Description
23
24
25
26
27
29
30
31
32
33
34
35
Relay
36
37
38
39
40
41*
42*
43*
44*
45*
56084 Sensor Switch Holder
57355 Konavi Breeder Skirt
57395
KONAVI
57396 Chick Excluder
57354B Konavi Breeder Restrictor
3527 Hose Clamp
2529-1216 Konavi Prox Control Decal
48491 Top Cover w/Insulators
2527-9 Danger Decal
305 #10 Ext. Lock Washer
56275 Dol 26 Sensor
26982-1 1/2x14 Flex Conduit
2798 Anti-Roost Guard
4188 Anchor Plate
48511 Lock Spring
44794 Drive Tube Weldment
56081 Konavi Cut Sleeve
23810 1/2" Ell Liquid Tight Connector
24062 1.75" Tube Clamp
3357 .50 Conduit Lock Nut
4642 Drive Block
5083-8 1/4-20 Socket Hd. Cap Screw
*Included in 43233 End Control Hardware Package
®
Breeder Pan
