Konavi® Pullet Feeding System
7.Rotate the Excluder and insert the Tabs on the Excluder into the Slots in the Pan.
8.With all Excluder Tabs fully inserted into the slots in the Feeder Pan, rotate the Excluder Counter-Clockwise
until the Excluder Snap Lock (Item 1) is locked in place.
MF2514A
1
Item Description
1 Snap Lock
Figure 17.Lock Excluder in place
Assembling Feeder
