KONAVI
Feeding System
®
Installation and Operators Manual
For additional parts and information, contact your nearest Chore-Time distributor or representative.
Find your nearest distributor at: www.choretime.com/contacts
August 2020
MF2464C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KONAVI and is the answer not in the manual?

Questions and answers

Related Manuals for Chore-Time KONAVI

Summary of Contents for Chore-Time KONAVI

  • Page 1 KONAVI Feeding System ® Installation and Operators Manual For additional parts and information, contact your nearest Chore-Time distributor or representative. Find your nearest distributor at: www.choretime.com/contacts August 2020 MF2464C...

  • Page 2: Table Of Contents

    Chore-Time Limited Warranty........
  • Page 3 KONAVI® MECHANICAL MID LINE CONTROL 56130........

  • Page 4: Chore-Time Limited Warranty

    Warranty period (“Extended Warranty Period”) with respect to certain Product parts (“Component Part”) as set forth in the table below. If such a defect is determined by Chore-Time to exist within the applicable period, Chore-Time will, at its option, (a) repair the Product or Component Part free of charge, F.O.B. the factory of manufacture or (b) replace the Product or Component Part free of charge, F.O.B.

  • Page 5: About This Manual

    KONAVI® Feeding System About This Manual About This Manual The intent of this manual is to help you in two ways. One is to follow step-by-step in the order of assembly of your product. The other way is for easy reference if you have questions in a particular area.

  • Page 6: Safety Instructions

    Safety Instructions KONAVI® Feeding System Safety Instructions Follow Safety Instructions Carefully read all safety messages in this manual and on your equipment safety signs. Follow recommended precautions and safe operating practices. Keep safety signs in good condition. Replace missing or damaged safety signs.

  • Page 7: General Installation Information

    General Installation Information Important! Please read all installation instructions in this manual prior to beginning the installation. This manual provides the necessary information on the installation, operation, and maintenance of the Chore-Time feeding equipment you have purchased. ® The KONAVI Control Units •348 RPM Gearhead Delivering 17 lbs [7.7 kg] per minute if density of 40 lbs per cubic foot [640 kg per...

  • Page 8: Manufacturer's Recommendations: Birds Per Pan

    * NOTICE: The above Manufacturer’s recommendations do not constitute a product warranty and are in no way to be considered as a guarantee of performance for poultry production. In addition, the above information in no way alters or revises the terms and conditions of any applicable Chore-Time manufacturer’s warranty. MF2464C...

  • Page 9: Suspension System

    KONAVI® Feeding System Suspension System Suspension System Planning the Suspension System Optional Mid Line Controls may be used for partial house brooding. (See Figure 1.) 10’[3m] Minimum 10’[3m] Minimum Item Description Item Description Brood Curtain End Control and Power Unit...

  • Page 10: Laying Out The Suspension System

    Laying out the Suspension System Systems over 350' [107 m] Detail "A" Detail "C" Detail "D" Detail "B" 8’ [2.4m] Maximum Maximum 3’ [90cm] Distance of Distance of Maximum Travel Travel +2" [61cm] Wood Framed House: Requires Support Spanning 3 Trusses Steel Framed House: Requires Support Spanning 2 Trusses 22"...

  • Page 11: Systems Up To 350' [107 M]

    Systems up to 350' [107 m] Detail "A" Detail "B" 1’ [30cm] 3’ [1m] Wood Framed House: Requires Support Spanning 3 Trusses Steel Framed House: Requires Support Spanning 2 Trusses Item Description Swivel Pulley Hopper Support Winch Support Roof Truss Detail "B"...

  • Page 12: Installing The Suspension System

    Installing the Suspension System Power Lift Winch Installation Power Lift Winch Support (Steel or Wood) Steel Truss Installation Wood Truss Installation Item Description Power Lift Winch Support: 2'' x 8'' [50 x 200 mm] board spanning at least 3 trusses. Power Lift Winch Truss Cable Hook: Install as shown.
  • Page 13 Attaching Winch Support to Trusses Item Description Feeder Line Winch & Winch Support Winch Centered on Feeder Wood Truss Installation line unless Feed Hopper is centered. Winch Centered directly over Feeder Line Hopper (End of Feed line option) Hopper (Center of Feed line option) End Control Lag Bolts...

  • Page 14: Cable Installation

    Installing the Suspension System KONAVI® Feeding System Cable Installation Important! Special Support Required at Hopper Location if the Hopper is not directly under a Truss. Special Support at Hopper Locations (Wood Construction) Item Description Feeder Line Hopper Centered on Feed...
  • Page 15 KONAVI® Feeding System Installing the Suspension System Support at Power Unit Location 3’ [91.4 cm] Maximum 3’ [91.4 cm] Wood Construction (Not directly under Truss) Maximum 3’ [91.4 cm] Maximum Steel Construction (Not directly under Truss) Item Description Power Unit Drop Pulley 1st Feed Line Drop Pulley 2"...
  • Page 16 Installing the Suspension System KONAVI® Feeding System Attaching the Main Winch Cable (Temporarily) Plan for a Double-Back Pulley arrangement if over 350’ [107m] (See Figure 10.) Item Description Fasten Cable with Nails, Staples, Etc. Double Back Pulley Installations (Feed Lines over 350’ [107m]) Figure 10.Temporarily Attaching Main Winch Cable to Ceiling...
  • Page 17 KONAVI® Feeding System Installing the Suspension System Screw Hook Installation If distance raised (3) is greater than (2) then stagger Screw hooks (4) as shown. View up to Ceiling Item Description Part No. 3" [7.6 cm] Offset Distance of Cable Travel (Recommended 8’ [2.4m] on center). Do Not exceed 10’ [3m].

  • Page 18: Hopper Suspension

    3/32" [2.4 mm] or 1/8" [3.18 mm] Cable Pull Direction (Toward Winch) 3/16" Cable Clamp 6" [150 mm] Cable Lock (Adjustment Leveler) See 14337 Figure 28. on page 24. Figure 16.Drop Installation Throwback arrangement Hopper Suspension See Chore-Time Manual MF1819 for Hopper Assembly and installation procedure. MF2464C...

  • Page 19: Assembling Feeder

    KONAVI® Feeding System Assembling Feeder Assembling Feeder 1.Insert the Quarter Turn Key (55818) into the Key-hole of the Chick Excluder (55821). Note: Only one leg of the Chick Excluder has the Key-hole. 2.Push on the Quarter Turn Key until it snaps into place.

  • Page 20: Installing Feeder On Feed Tube

    Assembling Feeder KONAVI® Feeding System 5. Push down and Rotate the Chick Excluder until it snaps in place and turn the Quarter turn Key Clockwise 90°. Chick Excluder Quarter Turn Key Key-way Figure 19.Rotating Excluder to position and lock in place with Quarter Turn Key Note: Cap can be installed and Feeder can be slid onto Pipe, or Feeder can be installed onto Tube at any location.
  • Page 21 KONAVI® Feeding System Assembling Feeder Installing Cone Cap (All Feeders) 1.Line up the Feeder with the hole in the Feeder Tube. 2.Set a Cone Cap (55820) on the Auger Tube, and with the Tabs of the Cone Cap captured by the Cone, Slide it past the Locking Tabs so it locks into place as shown.

  • Page 22: Feeder Line Assembly And Suspension

    Feeder Line Assembly and Suspension KONAVI® Feeding System Feeder Line Assembly and Suspension Feeder Pan and Tube Assembly Process 1.Slide one Feeder Pan Assembly per hole onto the auger tubes. IMPORTANT: Install all the feeders on the tubes in the same orientation.
  • Page 23 KONAVI® Feeding System Feeder Line Assembly and Suspension 3.To achieve total feed drop out all along the system, the Chore-Time Logo should be centered at the crown of the tubes and all the Hangers should be installed as shown in Figure 24.
  • Page 24 Chore-Time Logo is on crown of tube. make sure the clamps are located, as shown in Figure 26. Finally, tighten the Tube Clamps on the feeder tubes. Clamp the joints securely, but do not crush the tubes.

  • Page 25: Installing The End Control And Boot Assembly

    KONAVI® Feeding System Installing the End Control and Boot Assembly Installing the End Control and Boot Assembly The End Control Unit must be at least 10 feet [3 m] from the end of the building to allow birds access around the end of the feeder line.

  • Page 26: Auger/End Control Installation

    Auger/End Control Installation KONAVI® Feeding System Auger/End Control Installation Note: Use extreme caution when working with the auger. The auger is under tension and may spring causing personal injury. Wear protective clothing, gloves, and safety glasses when working with the auger.
  • Page 27 KONAVI® Feeding System Auger/End Control Installation 4.Slide the Drive Tube and flat washer over the output shaft on the Power Unit, as shown in Figure 32. 5.Continue installing auger until the auger reaches the Control Unit end of the feeder line.
  • Page 28 Auger/End Control Installation KONAVI® Feeding System 8.Install the Metal Water Tight Connector (Item 1) in the Power Unit (Item 2). Cut the Flex Conduit (Item 3) to length. Slide the wires from the end control through the Flex Conduit (Item 3). Install the Flex Conduit (Item 3) in the connectors.
  • Page 29 KONAVI® Feeding System Auger/End Control Installation 13.Insert the Anchor Assembly into the auger until it touches the washer at the back of the anchor. Tighten the setscrews in the center of the anchor until they touch the auger, then tighten a maximum of 1/2 turn. See Figure 36.

  • Page 30: Mid-Line Control

    The Mid-Line Control makes it possible to operate the feeding system when birds are confined away from the End Control Unit. Chore-Time recommends placing the Mid-Line Control Feeder at least 2 pans away from the curtain or partition. (See Figure 39.)

  • Page 31: Installation

    KONAVI® Feeding System Mid-Line Control Installation Feeder Tube Outlet Holes Auger Tube New Feeder Lines: Skip to next section. Seam Existing Feeder Lines: Enlarge the outlet hole to approximately 1'' [2.5 cm] diameter for the Mid-Line Control, plus enlarge (2) outlet holes in front (to the hopper end) of the Mid-Line Control.
  • Page 32 4.Wire the Mid-Line Control as shown in the wiring diagram section of this manual. Outlet Hole in Auger Tube Lock Top in place Item Description Part No. Midline Control 56129 Tube Clamp 3527 Konavi Two Piece Top 55820 Figure 42. Installing the Mid-Line Control with Proximity Sensor MF2464C...

  • Page 33: Anti-Roost Assembly

    KONAVI® Feeding System Anti-Roost Assembly Anti-Roost Assembly 1.Unroll the bulk anti-roost cable. Note: If the cable is unrolled as shown in Figure 43., taking 5 loops of the coil with one hand, then changing hands to remove 5 loops as it is unrolled, it will lie flat during installation.
  • Page 34 Anti-Roost Assembly KONAVI® Feeding System 9.At the control unit, after clamping the cable to the spring, cut the cable about 8" to 10" [200 to 250 mm] longer than necessary. Feed the end of the cable through the center of the spring, around the first insulator on the control unit, and clamp the cable using the cable clamp supplied with the control unit.

  • Page 35: Wiring

    KONAVI® Feeding System Wiring Wiring End Control with Proximity Switch Internal Wiring End Control Unit Power Cord Feed Line Control Tube Ground Green To Motor Green White Brown Tube Clamp Black (Anti Roost) From Sensor White Blue Proximity Sensor Wiring Diagram...

  • Page 36: Mechanical Switch Single Phase Wiring Diagram

    Wiring KONAVI® Feeding System Mechanical Switch Single Phase Wiring Diagram From disconnect or Control disconnect Feeder Line Motor 220/230 220/230 Volts 50/60 HZ Volts 50/60 HZ. Single Phase End Control Mid-Line Unit Control Unit Single Phase Single throw Switch 15 amp (Not Supplied) Mechanical Switch Single PhaseWiring Diagram with Motor Starter...

  • Page 37: Mechanical Switch Three Phase Wiring Diagram: 220 V

    KONAVI® Feeding System Wiring Mechanical Switch Three Phase Wiring Diagram: 220 V. From disconnect or Control disconnect 220 Volts 50 HZ Three Phase To additional Feeder Lines Phase Phase Phase Set of Fuses short circuit protection Control Bypass Switch (Not Supplied)

  • Page 38: Electronic Sensor Three Phase Wiring

    Electronic Sensor Three Phase Wiring From disconnect or Control disconnect 220/380 Volts 50 HZ Three Phase To additional Feeder Lines Phase Phase Phase Neutral Set of Fuses short circuit protection (Not Supplied) Contactor Control Bypass Mid-Line Switch (Not Supplied) Control Sensor 3 PH Feeder Line Motor...

  • Page 39: Power Unit Wiring

    KONAVI® Feeding System Wiring Power Unit Wiring 3259-84 Power Unit (4229 Motor) Wiring T1 or Blue T8 or Red Line Line J9 or Black J12 or Purple T4 or Yellow 3259-85 Power Unit (5703 Motor) Wiring Green Ground Blue Green...

  • Page 40: 3259-100 Power Unit (28031 Motor) Wiring

    Wiring KONAVI® Feeding System 3259-100 Power Unit (28031 Motor) Wiring 220V-240V 380V-400V Green Grd. (If req’d) Low V Y High V W2 U2 V2 W2 U2 V2 U1 V1 W1 U1 V1 W1 L1 L2 L3 L1 L2 L3 3259-128 Power Unit (24624 Motor) Wiring...

  • Page 41: Troubleshooting

    KONAVI® Feeding System Troubleshooting Troubleshooting ALWAYS DISCONNECT POWER TO THE SYSTEM WHEN SERVICING OR MAINTAINING THE EQUIPMENT. FAILURE TO DISCONNECT POWER MAY CAUSE INJURY OR DEATH. Service and maintenance work should be done by a qualified technician only. Problem Possible Cause...

  • Page 42: Maintenance

    Maintenance KONAVI® Feeding System Maintenance Floor Feeding System Maintenance ® The KONAVI Feeders require minimum maintenance. However, a routine periodic inspection of the equipment will prevent unnecessary problems. Maintenance should be done by a qualified technician. ALWAYS DISCONNECT POWER TO THE SYSTEM WHEN SERVICING OR MAINTAINING THE EQUIPMENT.

  • Page 43: Mechanical Switch Adjustment Procedure For Control Units

    KONAVI® Feeding System Maintenance Mechanical Switch Adjustment procedure for Control Units Refer to (See Figure 49.) Adjustment A. Turn the adjustment nut counter-clockwise until the switch clicks. B. Turn the adjustment nut clockwise until the switch clicks. C. Turn the adjustment nut counter-clockwise 3/4 turn.

  • Page 44: Feeder Line

    Maintenance KONAVI® Feeding System Feeder Line Keep anti-roost cables tightly stretched. This increases the effectiveness of the electro-guard anti-roost system and keep the pans from being tilted when birds push against them. Remove all feed from the feeder when there are no birds in the house and when the building is washed and disinfected.

  • Page 45: Management

    KONAVI® Feeding System Management Management This section provides you with valuable information concerning feeder operation and management. It is important that you read this information and understand how the feeding system was designed to operate. Once you become familiar with the system, you may custom operate it to fit your individual needs.

  • Page 46: To Operate

    Do not operate the feeding system on automatic (full demand feed) when the feed windows are open. Chore-Time recommends opening the feed windows for the first 3 to 5 days (max). The feeders will need to be operated at least 2 times a day for the first 5 days, and thereafter, 3 times a day or more as needed, while the windows are open.

  • Page 47: Controlling The Feeders (Optional Equipment)

    KONAVI® Feeding System Management As the birds grow and become acclimated to the feeder pans, the feeder will need to be raised to the grow-out position. Before raising the feeder, it is recommended to allow the birds to eat the feed level down below the feed flood windows.

  • Page 48: Parts List

    Parts List KONAVI® Feeding System Parts List 150# Plastic Hopper Item Description 48926 49267 Hopper Hopper Switch Backup Plate 50966 50966 Plastic hopper half 49028 49028 Hopper cover 48675 Support cable assembly 2809-3 2809-3 Clevis pin 2797-1 2797-1 Boot adjuster bracket...

  • Page 49: 200# Hopper Components

    KONAVI® Feeding System Parts List 200# Hopper Components 7941 28358 Hopper Assembly Hopper Ass’y with cover Item Description Part No. Hopper Cover 28206 Tube Support Assembly 14367 14367 Hopper Side 2680 2680 Boot Hanger 2671 2671 Hanger Bracket Assembly 2681...

  • Page 50: 100 # Hopper Components

    Parts List KONAVI® Feeding System 100 # Hopper Components 28210 28220 28240** 100 lb. Hopper Cover Ass’y. 100 lb. Hopper Assembly 100 lb. Hopper & (No Cover) Cover Assembly Description Part No. Hopper Cover (w/o hole) 28211 Hopper Cover (w/ hole)

  • Page 51: Hopper Mount Bracket

    KONAVI® Feeding System Parts List Hopper Mount Bracket Part Number 49358 - Hopper Suspension Kit Item Description Part No. Part No. Single Boot Twin Boot Clevis Pin, 5/16'' x 1'' 2797-1 2797-1 Adjustment Bracket 2706 2706 Hair Pin 2664 2664...

  • Page 52: Twin Boot Components Part No. 6824

    Parts List KONAVI® Feeding System Twin Boot Components Part No. 6824 1523-14 8/2004 Item Description Part No. Item Description Part No. Boot Weldment 3760 Anchor 38540 Tube Clamp 24063 5/16-18x7/8” Sock Hd Screw 47867 29373 Anchor and Bearing Ass’y 39372...

  • Page 53: Feeder Line Components

    KONAVI® Feeding System Parts List Feeder Line Components Item Description Part No. 1/16'' Cable 1922 Charger Wire (165') 28994-165 Charger Wire (330') 28994-330 Spring 7551 1/16'' Cable Clamp 1826 Auger 6820-0 Tube Clamp 24063 Anti-Roost Bracket 24060 Hanger KIT 51763 Standard Feeder Tube-1 3/4"...

  • Page 54: Konavi® Pan Assembly

    Parts List KONAVI® Feeding System ® KONAVI Pan Assembly ® All KONAVI Pan Assemblies come with a Two Piece Top. ® ® KONAVI Broiler Pan KONAVI Broiler Pan With Slide Shutoff Part No. 55826 Part No. 55825 ® KONAVI Colony Pan ®...

  • Page 55: Power Unit Assemblies

    KONAVI® Feeding System Parts List Power Unit Assemblies Item Description 3259-84 3259-85 3259-98 3259-100 3259-128 Part No. Part No. Part No. Part No. Part No. Pinion Assembly 5046 5046 5046 5046 5046 - - - - - - - -...

  • Page 56: Konavi® Mechanical End Control 56070

    ® KONAVI Mechanical End Control 56070...
  • Page 57 Part No. Description Item Part No. Description 55816 Feed Cone Skirt 46122 Switch Bracket 55819 1907-5 Switch Insulation KONAVI ® Feeder Pan 25495 Control Cord Assembly 34019 10-24 Lock Nut 8757 1/8 Round Head Rivet 6723 Flat Washer 7007 10-32 Stud...

  • Page 58: Konavi® Proximity Sensor End Control 56123

    ® KONAVI Proximity Sensor End Control 56123...
  • Page 59 Control Body Sensor #10 Ext. Lock Washer 34660 6-32 x .375 SFTP Screw 23779 Liquid Tight Connector 55821 Chick Excluder 55820 ® KONAVI Two Piece Top 56125 Machined Support Cone 55816 Feed Cone Skirt 55819 ® KONAVI Feeder Pan 2527-9...

  • Page 60: Konavi 56129 Proximity Sensor Mid Line Control

    Parts List KONAVI® Feeding System ® KONAVI 56129 Proximity Sensor Mid Line Control Wire Terminal Mf2464-150 11/2/17 Item Part No. Description 55819 ® KONAVI Feeder Pan 56078 ® KONAVI Support Cone Assembly 55821 ® KONAVI Chick Excluder 55818 ® KONAVI...

  • Page 61: Konavi® Mechanical Mid Line Control 56130

    KONAVI® Feeding System Parts List ® KONAVI MECHANICAL MID LINE CONTROL 56130 21 15 28 27 Mf2464-152 11-17 Item Part No. Description Item Part No. Description 4999-49 Cord Assembly 55819 ® KONAVI Feeder Pan 8757 1/8 x 1 Rivet 56078 ®...

  • Page 62: 2883 Power Winch

    Parts List KONAVI® Feeding System 2883 Power Winch 1660-25 2/2001 Item Description Part No. Item Description Part No. Input Shaft Assembly Drive Pinion 2962 Manual 42665 Electric 42666 Flange Bushing 2967-2 Woodruff Key 2959 Drive Stud 4128-1 1" Bearing 4937...

  • Page 63: Miscellaneous Suspension Components

    KONAVI® Feeding System Parts List Miscellaneous Suspension Components Item Description Part No. 3/16 Cable 1213 Cable Lock 14337 Pulley with Swivel 3004 Heavy Duty Pulley Assembly 2014 Pulley 2500 3/16" Cable Clamp ATF Screw Hook 2041 Extendable drive tube 47637...
  • Page 64 Revisions to this Manual Page No. Description of Change Various Updates 34683 For additional parts and information, contact your nearest Chore-Time distributor or representative. Find your nearest distributor at: www.choretime.com/contacts CTB, Inc. PO Box 2000 Milford, Indiana 46542-2000 USA Phone (574) 658-4101 Fax (877) 730-8825 Email: choretime@choretime.com...
