Installing the End Control and Boot Assembly

The End Control Unit must be at least 10 feet [3 m] from the end of the building to allow birds access around the
end of the feeder line.
1.Assemble the End Control Unit to the Feeder Line Control Tube using a clamp/anti-roost bracket. See
Figure 23. DO NOT INSTALL THE POWER UNIT AT THIS TIME.
Figure 23.Connecting End Control Unit to the Feed Line Tube
2.Install the Feeder Boot (Item 1) by sliding the straight end of the Feeder Boot into the belled end of the
Feeder Tube. Install a Clamp Assembly (Item 2) and Anti-roost Bracket (Item 3) on the bell and tighten.
4
2
26
6
4
5
4
Item
1 Feeder Boot
2* Tube Clamp Assembly
3 Anti-roost Bracket
4* 1/4-20 x 2.5 Carriage Bolt
5* 1/4-20 Flange Nut
*Included in 24063-X Tube Clamp Kit
Figure 24.Installing the Feeder Boot
3
Item
5
1
2
Description Part No
--
24062
24060
7550-3
46460
Konavi® Pullet Feeding System
Description
1 Control Tube
2 Tube Clamp Assembly
3* 1/4-20 x 2.5 Carriage Bolt
4* 1/4-20 Flange Nut
5 Anti-roost Bracket
6 End Control Unit
*Included in 43233 Hardware Package
1
Part No.
--
24062
7550-3
46460
24060
--
MF2514A
