Konavi® Pullet Feeding System

Drop Installation

1
3
7
Attaching Ceiling Hooks

Throwback Cable Arrangement

Cable included for Throwback pulleys beneath or near Winch (See Figure 15.)
3
2

Hopper Suspension

See Chore-Time Manual MF1819 for Hopper Assembly and installation procedure.
MF2514A
5
4
2
8
Figure 14.Standard Drop arrangement
1
3
4
5
6
Figure 15.Drop Installation Throwback arrangement
3
6
Item
1 Pulley
2 3/32" [2.4 mm] or 1/8" [3.18 mm] Cable
3 Pull Direction (Toward Winch)
4 3/16" Cable Clamp
5 6" [150 mm]
6 Cable Lock (Adjustment Leveler) See
"Adjustment Leveler Installation" on
page 23.
7 1/4-20 Lag bolt
8 Ceiling Hook
3
Item Description
1 Pulley
2 3/32" [2.4 mm] or 1/8" [3.18 mm] Cable
3 Pull Direction (Toward Winch)
4 3/16" Cable Clamp
5 6" [150 mm]
6 Cable Lock (Adjustment Leveler) See
"Adjustment Leveler Installation" on
page 23.
Description
Part No.
Installation
Part No.
3004
--
--
732
--
14337
--
28550
3004
--
--
732
--
14337
