Chore-Time Konavi Pullet Feeding System Installation And Operator's Manual page 59

Item Part No. Description
1 57430 Konavi Breeder Cone
2 57355 Konavi Breeder Skirt
3 57396 Chick Excluder
4 57354B Konavi Breeder Restrictor
5 57395
®
KONAVI Breeder Pan
6* 3527 1.875 Hose Clamp
7 56084 Switch Holder
8 52315 Mounting Bracket
9 6956 Mounting Terminal Box Cover
10 6777 Switch Box Gasket
11 42627-13 General Purpose Box
12 52316-2 Control Panel Relay Mount
13 28904 Relay
14 34019 10-24 Nylon Hx Lock Nut
15 35493 4-24 x /375 Phil PH Screw
16 34660 6-32 x 3/8 Phil. Pan. Hd. Screw
17 6776 Terminal Box Cover
18 2526-377 Date of Manufacture Decal
19 2529-1217 Konavi Breeder Mid Line Decal
20 28075 #10 x .5 HXWH Screw
21 23779 Liquid Tight Connector
22 43662 .50 Conduit Lock Nut
23 56275 Proximity Sensor
24 305 #10 Ext. Lock Washer
25 4999-114 Cord Assembly
26 56753 Konavi Breeder Cap
27* 14484 Locking Pin
*Two Clamps and Locking Pin Included in 14485 Anti-Swing
Clamp Kit.
