- Page 1 Circulating Feed Delivery System Installation Instructions Model 55, 75, 75 Stainless, 75 PLUS, 75 Plus Stainless, ® 90, & HMC FLEX-AUGER Feed Delivery Systems August 2019 MA773H...
- Page 2 One (1) year from the date of installation by the original purchaser (“Warranty”). If such a defect is determined by Chore-Time to exist within the applicable period, Chore-Time will, at its option, (a) repair the Product or Component Part free of charge, F.O.B. the factory of manufacture or (b) replace the Product or Component Part free of charge, F.O.B.
-
Page 3: Table Of Contents
Wiring ............... . . 8 Models 55, 75/SS, 90, and HMC Single Phase, 230V, 50/60 Hz, w/o Motor Starters ... . . 8 Model 75 Plus/SS Single Phase, 230V, 50/60 Hz, w/o Motor Starters . -
Page 4: General
General General The Chore-Time Circulating Feed Delivery System is designed to Deliver Feed to deliver Feed in a Livestock application. Using this equipment for any other purpose or in a way not within the operating recommendations specified in this manual will void the warranty and may cause personal injury. -
Page 5: Safety Information
Extension Hopper Safety Information Caution, Warning and Danger Decals have been placed on the equipment to warn of potentially dangerous situations. Care should be taken to keep this information intact and easy to read at all times. Replace missing or damaged safety signs. Using the equipment for purposes other than specified in this manual may cause personal injury and or damage to the equipment. -
Page 6: Auger Caution
The Circulating Feed Delivery System allows multiple feedings at random locations around the system without overloading or jamming the system with feed. Many variations are possible using the Model 55, 75, 75 Stainless, 90, 75 PLUS, 75 Plus Stainless, or HMC FLEX-AUGER. -
Page 7: Over And Under Feed Delivery System
Safety Information Extension Hopper Over and Under Feed Delivery System Over and Under- Another proposed plan is shown in Figure 2. No Elbows are required for this circulating system. This plan is typically used to supply feed to multiple lines or loops running independent of one another. -
Page 8: Wiring
Extension Hopper Wiring Wiring Models 55, 75/SS, 90, and HMC Single Phase, 230V, 50/60 Hz, w/o Motor Starters MA773H... -
Page 9: Model 75 Plus/Ss Single Phase, 230V, 50/60 Hz, W/O Motor Starters
Wiring Extension Hopper Model 75 Plus/SS Single Phase, 230V, 50/60 Hz, w/o Motor Starters MA773H... -
Page 10: Single Phase, 230V, 50/60 Hz, W/ Motor Starters
Extension Hopper Wiring Single Phase, 230V, 50/60 Hz, w/ Motor Starters MA773H... -
Page 11: Three Phase, 230/380/415/460V, 50/60 Hz
Wiring Extension Hopper Three Phase, 230/380/415/460V, 50/60 Hz MA773H... -
Page 12: Part Numbers
Extension Hopper Wiring Part Numbers Extension Hopper Part Numbers MA773H... -
Page 13: Parts List
*These Anchor and Bearing Components may be ordered as complete Assemblies under the following Part Numbers: Model 55 (39405), Model 75/SS (37347), Model 75 Plus/SS (56417), Model 90 (35345), Model HMC (37241) **These Switch and Plate components may be ordered as an assembly under Chore-Time part number #7840/SS ***The #7839/SS Cover Assembly includes items 6, 14, 15, and 16 and the required hardware. - Page 14 Description of Change Various Added 75 Stainless, 75 Plus, and 75 Plus Stainless 34341 For additional parts and information, contact your nearest Chore-Time distributor or representative. Find your nearest distributor at: www.choretime.com/contacts Chore-Time Group, A division of CTB, Inc. PO Box 2000...
