Planning the Suspension System

Systems with line lengths over 300' [91 m] should be split in the center, as shown in Figure 1. This will reduce auger
running time and eliminate the need for Mid-Line Controls for partial house brooding.
Center Fill is recommended. 1/4 house brooding can be accomplished by using only two feed lines when chicks are
placed. This is the recommended method.
If Mid-Line Controls are used for 1/4 house brooding, DO NOT index the Feed Tubes that include Mid-Line Controls.
10'[3m] Minimum
to Power Unit
2
3
8
Item Description
1 Brood Curtain
2 Control Tube
3 End Control and Power Unit
4 Feeder Hopper
5 Feed Bin
6 Optional Mid-Line Control
Figure 1. Component location diagram
Konavi® Pullet Feeding System
10'[3m] Minimum
to Power Unit
1
6
4
5
Optional Mid-Line Control
2
3
MF2514A
