Appendix | ASCII Communication with Controller

A 3.3.10.5 Statistics Eample

The commands are executed with the Telnet program, no statistical values have been defined.
->o 169.254.168.150
. _ _ _ _ _ _ _ _ _ .
/ _ _ _ \
/ | | / ) \
| | | \ _ _ _ |
| | | / |
\ | \ _ / | / \ _ _ _ ) /
‚ |
Connected with the MICRO-OPTRONIC terminal server.
Your IP 169.254.168.1, your local port number 51719. You
are connected to port number 23.
->META_STATISTICSIGNAL
META_STATISTICSIGNAL 01PEAK01
->STATISTICSIGNAL 01PEAK01 256
->STATISTICSIGNAL
STATISTICSIGNAL 01PEAK01 256
STATISTICSIGNAL NONE
STATISTICSIGNAL NONE
...
STATISTICSIGNAL NONE
->OUT_ETH 01PEAK01_MIN
->OUTPUT ETHERNET
->STATISTICSIGNAL 01PEAK01 NONE
W526 Output signal selection modified
by the system
IMS 5x00
// List of all controller signals that can be used to calculate statistical
signals.
// Use the last 256 values of the signal 01PEAK01 to calculate the statisti-
cal values 01PEAK01_MIN, 01PEAK01_MAX and 01PEAK01_PEAK
// List all 10 possible variables and show their state.
// In the web interface, go to the Measurement chart tab to show the
statistical signals.
//
Selects the minimum value for output via the Ethernet interface.
// Activates output via Ethernet.
// Ends statistical calculation for the signal 01PEAK01
