Advanced Settings
7.6.7

Reset Controller

This menu section enables to reset the individual settings to factory settings. This menu requires the Expert user level.
Measurement settings
Device settings
Reset of the material table
Reset all
Reboot controller
7.6.8

Light Source

You can turn on or off the SLED (light source) and the pilot laser.
7.6.9

Material Table

This menu item enables you to compare the settings of the listed materials or to add a new material.
7.6.10

Switching between Ethernet and EtherCAT

This setting defines the connection log when the controller is started. You can also switch between Ethernet and Ether-
CAT via an ASCII command or EtherCAT object.
Save the current settings before switching to EtherCAT.
Switch to the Settings > System settings menu and select EtherCAT as the interface.
Click on the
The switch becomes active only after restarting the controller. The web interface is not available in EtherCAT mode.
The RS422 interface for sending an ASCII command is available both in Ethernet mode and in EtherCAT mode.
Grey shaded fields require a selection.
IMS5x00
Resets the preset to Mat and all parameters (except for interface settings) to
factory setting.
Reset the Ethernet interface to factory settings.
Reset the material table to factory settings.
Reset the device and measurement settings to factory settings.
Starts the controller with the last saved settings
button.
Value
Fields with dark border require entry of a value.
