Appendix | EtherCAT Documentation

A 4.4.2.28 Object 25A1: Encoder3

Sub-indices
0 VAR Number of entries
1 VAR Encoder3 enable
2 VAR Encoder3 interpolation
3 VAR Encoder3 initial value
4 VAR Encoder3 maximal value x
5 VAR Encoder3 set value

A 4.4.2.29 Object 2711h: Masking the Evaluation Range

2711 RECORD Range of interest
Sub-indices
0 VAR Number of entries
1 VAR Range of interest start
2 VAR Range of interest end
For more information, please refer to the Masking the Evaluation Range section, see

A 4.4.2.30 Objekt 2800h: Material Information

2800 RECORD Material info and edit
Sub-indices
0 VAR Number of entries
1 VAR Material name
2 VAR Material description
3 VAR group index
For more information, please refer to the Material Database section, see
- Material name: Currently selected material for a thickness measurement
- Material description: Description of the currently selected material
- group index: Refractive index of the currently selected material at 845 nm
The current material can be edited in Expert mode. Specified settings are stored immediately.

A 4.4.2.31 Object 2802h: Edit Material Table

2802 RECORD Material table edit
Sub-indices
0 VAR Number of entries
1 VAR Material delete
2 VAR Reset materials
3 VAR New material
4 VAR Select material for edit
- Material delete: Specifiy the name of a material to be deleted from the material table
- Reset Materials: Resets the material table to the factory settings
- New material: Creates a new material in the material table. The newly created material („NewMaterial") is edited in
object 2800h „Material info".
Sub-index 4 selects the material that is to be edited in object 0x2800.
IMS 5x00
5 Unsigned8
x Bool
x Unsigned8
x Unsigned32
Unsigned32
False Bool
2 Unsigned8
x Unsigned16
x Unsigned16
7 Unsigned8
xxxxx Visible String rw
xxxxxx Visible String rw
x.xxxx FLOAT32
4 Unsigned8
x Visible String wo
x BOOL
x BOOL
Visible String wo
ro
rw
rw
ro
ro
ro
ro
rw
rw
Chap. 7.2.2, see
ro
rw
Chap. A 3.3.9.
ro
wo
wo
Chap. A 3.3.8.2.
Page 128
