A 4.4.2.32 Object 2803h: Existing Materials

2803 RECORD Material table
Sub-indices
0 VAR Number of entries
1 VAR Material name list
Provides a list of all available materials: Air calibration / Air / BK7 / D263T / Ethanol / Fused Silica / LaSF9 / Mirror / N-SF6
/ PC / PMMA / PS / Vacuum.

A 4.4.2.33 Object 2804h: Select Material

2804 RECORD Material selection
Sub-indices
0 VAR Number of entries
1 VAR Material 1
...
E VAR Material
Specification of the material whose characteristics are included in the measured values
The selected material must be present in the materials table.

A 4.4.2.34 Objekt 2805h: Material between Sensor and 1st Layer

2805 RECORD Material in front
Sub-indices
0 VAR Number of entries
1 VAR Material
Indication of the material located between the sensor front face and the first layer of the target.

A 4.4.2.35 Object 2A00h: Mastering

2A00 RECORD Master 1
Sub-indices
0 VAR Number of entries
1 VAR Enable
2 VAR Signal
3 VAR Available signals
4 VAR Set/reset
5 VAR Value
Masters or sets to zero a signal; there are 10 such objects (2A00h to 2A09h). References the MASTERSIGNAL command.
The sub-index specifies which signal is to be mastered. Sub-index 3 corresponds to the META_MASTERSIGNAL com-
mand.
Sub-index 4 corresponds to the MASTER command.
