- Page 1 Instruction Manual ELTROTEC Endolight FOT Halogen 150...
- Page 2 Halogen light source MICRO-EPSILON Eltrotec GmbH Manfred-Wörner-Straße 101 73037 Göppingen / Germany Tel. +49 (0) 7161/ 98872-300 Fax +49 (0) 7161 / 98872-303 e-mail eltrotec@micro-epsilon.de www.micro-epsilon.com Certified acc. to DIN EN ISO 9001: 2008...
-
Page 3: Table Of Contents
Fuse Replacement ............................15 Changing the Lamp ............................16 Instructions for Operation ........................18 General ................................18 Cleaning ................................. 18 6.2.1 Housing and Power Supply ......................18 6.2.2 Quartz Glass of Light Source ....................... 18 ELTROTEC Endolight FOT Halogen 150... - Page 4 Warranty ..............................19 Service, Repair ............................19 Decommissioning, Disposal ......................... 19 Appendix Optional Accessories ..........................20 Spare Parts ............................. 23 Factory Setting ............................24 ELTROTEC Endolight FOT Halogen 150...
-
Page 5: Safety
Keep the light source away from liquids and splashes of water. NOTICE > Damage to or destruction of the light source The power supply must not exceed the specified limits. > Damage to or destruction of the light source ELTROTEC Endolight FOT Halogen 150 Page 5... -
Page 6: Notes On Ce Identification
10 by the authorities responsible at MICRO-EPSILON Eltrotec GmbH Manfred-Wörner-Straße 101 73037 Göppingen / Germany ELTROTEC Endolight FOT Halogen 150 light source is designed for use in industry and satisfies the requirements of the standards - EN 61000-6-1: 2007 - EN 61000-6-4: 2007 The system satisfies the requirements if they comply with the regulations described in the instruction manual for installation and operation. -
Page 7: Proper Use
- The system may only be operated within the limits specified in the technical data, see Chap. 2.2. - Use the ELTROTEC Endolight FOT Halogen 150 light source in such a way that in case of malfunctions or failure personnel or machinery are not endangered. -
Page 8: Functional Principle, Technical Data
Functional Principle, Technical Data Functional Principle, Technical Data Short Description ELTROTEC Endolight FOT Halogen 150 light source is regarded as the universal solution when using ex- ternal light sources in the endoscopy. The high light output and simple operation facilitate optimal inspection results. -
Page 9: Delivery
Delivery Delivery Unpacking - ELTROTEC Endolight FOT Halogen 150 light source - Halogen lamp Osram type HLX 64634 15 V / 150 W - Power supply cable You will find the suitable fiber optics and fiber-optic lighting units under Optional Accessories, see Chap. -
Page 10: Mounting
Light Source 180 (7.09) 240 (9.45) Fig. 1 Dimensions ELTROTEC Endolight FOT Halo- Fig. 2 Dimensions ELTROTEC Endolight FOT Halogen gen 150 front view 150 side view Dimensions in mm (inches), not to scale ELTROTEC Endolight FOT Halogen 150 Page 10... -
Page 11: Control Elements
Power input (Open for changing the lamp) Iris diaphragm control lever Fig. 3 Control elements front side and rear side Anti-rotating device keyway Fiber optic connection Economy switch, 2-position ON/OFF switch with control lamp ELTROTEC Endolight FOT Halogen 150 Page 11... -
Page 12: Operation
Check Always after switching on whether the built-in fan runs (noise). NOTICE > Destruction of the lamp, the heat protection filter and the iris diaphragm due to excessive heating. In case of a defective fan, turn the light source off immediately. ELTROTEC Endolight FOT Halogen 150 Page 12... - Page 13 The light intensity can be adjusted steplessly with the iris diaphragm control lever (3), see Chap. 4.2. The light adjustment is made by a mechanical iris diaphragm (without interference of the color temperature). ELTROTEC Endolight FOT Halogen 150 Page 13...
-
Page 14: Adjust The Input Voltage 110 / 230 V
5, using a screw driver and pull it out. Voltage selector element Positioning arrow Cut to raise the voltage selector element Power supply cable connection Fig. 4 Detail rear side of light source Fig. 5 Raise the voltage selector element ELTROTEC Endolight FOT Halogen 150 Page 14... -
Page 15: Fuse Replacement
Please use only the fuses recommended in the appendix under optional accessories (2 AT), see Chap. Insert the voltage selector element again and press on it. Pay attention onto the correct position of the operating voltage. Plug in again the power supply cable. ELTROTEC Endolight FOT Halogen 150 Page 15... -
Page 16: Changing The Lamp
Loosen the lamp out of the holder carefully (3), lift the spring clip slightly (4) and pull the lamp from the lamp socket (5). Remove the screw Fold down Remove lamp unit holder Holder ELTROTEC Endolight FOT Halogen 150 Page 16... - Page 17 Other settings are not required, as the holding system provides an optimum adjustment with a footprint up to 13 mm (maximum applicable fiber diameter). Close the front door and mount it again with the screw, see Fig. Plug in the power supply cable. ELTROTEC Endolight FOT Halogen 150 Page 17...
-
Page 18: Instructions For Operation
6.2.1 Housing and Power Supply Do not immerse Turn off the ELTROTEC Endolight FOT Halogen 150 light source and disconnect the power supply cable the device in water. from the wall socket and from the rear side of the device. -
Page 19: Warranty
The warranty period lasts 12 months following the day of shipment. Defective parts, except wear parts, will be repaired or replaced free of charge within this period if you return the device free of cost to MICRO-EPSILON Eltrotec. This warranty does not apply to damage resulting from abuse of the equipment and devices, from forceful handling or installation of the devices or from repair or modifications performed by third parties. -
Page 20: Appendix
EFL 1/4 1800 fiber bundle diameter: 4 mm MEP with Lemo 1 Length: 1800 mm adapter Cladding diameter: Metal protective conduit with PVC coating. One side FOT light source connector One side Lemo1 connector. ELTROTEC Endolight FOT Halogen 150 Page 20... - Page 21 150 mm, outer diameter Lightly angled, 3 mm, bundle diameter 2 mm for the UST/C illumination of drill holes, specially for tool making Rigid probe 21060547 Angled at 90°, UST/B, r = 10 mm ELTROTEC Endolight FOT Halogen 150 Page 21...
- Page 22 US2 mirror on fixture, ø 25 mm 21060431 USP mirror fixture Focussing lens 21060438 Focussing lens, UFL 21060438; attachable to UL fiber optic More fiber optics or faser-optic lighting units are available on request. ELTROTEC Endolight FOT Halogen 150 Page 22...
-
Page 23: A 2 Spare Parts
Endolight FOT 150 power switch 21310397 Endolight FOT 150 lamp socket inclusive flat connector 21310396 Endolight FOT 150 lamp holder with angle and retaining spring 21310395 Endolight FOT 150 heat protection filter 21310394 ELTROTEC Endolight FOT Halogen 150 Page 23... -
Page 24: A 3 Factory Setting
Endolight FOT 150 aperture holder with mounting ring + iris diaphragm 21310392 Endolight FOT 150 iris diaphragm 21310391 Endolight FOT 150 aperture holder for iris diaphragm 21310390 Power supply cable 1.5 m 21310402 Factory Setting Voltage input: 230 VAC operating voltage ELTROTEC Endolight FOT Halogen 150 Page 24... - Page 28 MICRO-EPSILON Eltrotec GmbH X9751285-A021059SWE Manfred-Wörner-Straße 101 · 73037 Göppingen / Germany Tel. +49 (0) 7161 / 98872-300 · Fax +49 (0) 7161 / 98872-303 *X9751285-A02* eltrotec@micro-epsilon.de · www.micro-epsilon.com...
