PM0215
4.4

SysTick timer (STK)

When enabled, the timer:
●
counts down from the reload value to zero,
●
reloads (wraps to) the value in the STK_RVR on the next clock cycle,
●
then decrements on subsequent clock cycles.
Writing a value of zero to the STK_RVR disables the counter on the next wrap.
When the counter transitions to zero, the COUNTFLAG status bit is set to 1.
Reading STK_CSR clears the COUNTFLAG bit to 0.
Writing to the STK_CVR clears the register and the COUNTFLAG status bit to 0. The write
does not trigger the SysTick exception logic.
Reading the register returns its value at the time it is accessed.
When the processor is halted for debugging the counter does not decrement.
Table 33.
Address
0xE000E010 STK_CSR
0xE000E014 STK_RVR
0xE000E018 STK_CVR
0xE000E01C STK_CALIB RO
System timer registers summary
Name Type Reset value
RW 0x00000000
RW Unknown
RW Unknown
0xC0000000
Doc ID 022979 Rev 1
Description
SysTick control and status register (STK_CSR)
on page 86
SysTick reload value register (STK_RVR) on
page 87
SysTick current value register (STK_CVR) on
page 87
SysTick calibration value register (STK_CALIB)
on page 88
Core peripherals
85/91
