Booster Pack Specifications - Futurecom PDR8000 Programming Manual

B P S
OOSTER ACK
General Specifications
Dimensions: Width / Height / Depth
AC Current at 120V AC
DC Current Drain
Operating Temperature, Full Power
setting;
At 50% Transmit Duty Cycle with case
At 100% Transmit Duty Cycle with case
External Connectors
Equipment Type Acceptance
Transmitter Specification
2022-08-25
PECIFICATIONS
488 mm (19.2") x 386 mm (15.2") x 185 mm (7.3")
Weight 23.2 lbs. / 10.5kg
AC Supply Voltage 100V AC to 240V AC, 47Hz to 63Hz
4.0A
DC Supply Voltage 13.8V DC -15%/+20%
Standby/Receive 0.7A
Transmit 14.3A
-30°C to 55°C
-30°C to 50°C
closed
open
RF Input N female, with Dustcap
RF Output N female, with Dustcap
AC Input powerCON TRUE1, NAC3MPX, with Sealing Cover
DC Input LEMO push pull, EGL.2K.302.CLA, with Dustcap
AUX LEMO push pull, EGG.1K.308.CLL, with Dustcap
Stainless steel stud, 0.5" long with 10-32 thread
Ground
CWWDSDTV100XX
FCC
7291A-
Industry Canada DSDTV100XX
Frequency Bands 136-174 MHz
RF Output Power
®
PDR8000 Portable Digital Repeater Programming Guide
VHF UHF
CWWDSDTUL50
CWWDSDTUH50
VHF UHF
380-430 MHz
450-470 MHz
50W
Document 8K088X04 R5.01
700/800
MHz
CWWDSDTJK50
700 MHz 800 MHz
764-776 MHz 851-869 MHz
Page 71 of 86
