Field Name
Station Configuration
Deployment Name
Deployment
Station Name
Hardware Platform
System Type
Site ID
Wireline Configuration
Wireline Interface
V.24 Transmit
Clock
2022-08-25
Options /
Units
Maximum 16 Name of the current Deployment
alphanumeric
characters.
Enabled/Disabled Enables/Disables the Deployment
Maximum 31 A unique name or alias that
alphanumeric identifies the PDR8000.
characters
except for _"? ' %
* .
PDR Identifies the hardware platform for
this PDR8000.
Satellite Rx
Satellite Tx
Conventional System type supported is
Conventional.
1-62 When the Wireline Interface is set
to V.24, this field is used as the
1
Terminal Endpoint Identifier
number.
None Select the wireline interface to be
used.
V.24
DFSI
Internal This specifies the source of the
V.24 Tx Clock. This is needed for
External
PDR8000 cross connect (RT/RT)
and some modems
Internal: The PDR8000 provides
the clock. This choice is typically
selected when the radio is
connected directly to an
infrastructure device.
External: An external device (e.g. a
Modem) is providing the V.24 clock.
®
PDR8000 Portable Digital Repeater Programming Guide
Description
Document 8K088X04 R5.01
Notes
Underscore may not be used
in the Deployment name as it
will be displayed as space on
the PDR8000 display.
This is a ready only field.
If None is selected, the other
Wireline Configuration fields
are disabled.
This field is enabled when
Wireline Interface is set to
V.24.
