Futurecom PDR8000 Programming Manual page 64

Field Name
PTT PTT OFF
PTT ON
CARRIER
Test Tone
V.52 Test Pattern
Repeater State Repeat Set up
Repeat Knocked
Down
Base station
Deployment 1-10
Channel 1-64
Toggle Gate Set Up/
Status
Knocked Down
Receiver Activity
Rx State Idle
Active
Rx Source Inbound
Outbound
Rx NAC
Rx PL/DPL
2022-08-25
Options / Description
Units
PTT OFF: PDR8000 not
transmitting
PTT ON: PDR8000
transmitting.
CARRIER: Carrier Tx only
Test Tone: Transmit 1011
digital test tone
V.52 Test Pattern: digital test
Signal
Indicates the PDR8000
repeat/base operation
Identifies the current
Deployment of the 10
possible deployments
Identifies the current channel
of the 16 possible channels
Toggles the Repeater Gate
Status between 'Set up' and
'Knocked Down' if Wireline
Interface is selected as'V.24'.
Refer to 'General
Configuration' of the
Deployment Settings.
Specifies the Receiver
Activity
Displays if the PDR8000 is
receiving from the Subscriber
or transmitting on V.24 Link.
Displays the received NAC
from the Subscriber
Displays the received PL/DPL
from the Subscriber
®
PDR8000 Portable Digital Repeater Programming Guide
User configurable- available in-
Service Mode only
Programmable in the Deployment's
General Configuration window
Repeater Operation.
Read only.
PDR8000 must have the V.24 option.
Document 8K088X04 R5.01
Notes
→
Page 64 of 86
