Field Name
Analog Code Link, Maximum
Table 10 alphanumeric
characters
PTT Priority W>R
R>W
R=W
RSSI Thresh. -50 to -127dBm
(dBm)
-100dBm
0-2550 seconds,
W.T.O.T. (sec)
in increments of
10 seconds
(0 = disabled,
displays as
OFF)
R.T.O.T. (sec) 0-2550 seconds,
in increments of
10 seconds
(0 = disabled,
displays as OFF)
(0 = disabled,
displays as
OFF)
R.D.O.D. (sec) 0-2550 seconds
0 seconds
2022-08-25
Options /
Units
Identifies by name and provides a
link to open the Channel – Analog
Code Table PL/DPL Assignments
window associated with the
current channel.
Specifies priority order of two
types of PTT requests:
• W = Wireline
• R = Rx of the Repeater
Received Signal Strength
Indicator Threshold specifies the
signal level at the input of the
PDR8000 receiver, required to
validate the signal
Wireline Time Out Timer specifies
the maximum amount of time the
transmitter may be continuously
activated through the wireline
signal.
Repeater Time Out Timer
specifies the maximum amount of
time repeater mode may be
continuously activated by
subscriber through receiver.
Repeater Drop Out Delay
specifies the amount of time
repeater mode is maintained
following loss of received signal.
®
PDR8000 Portable Digital Repeater Programming Guide
Description
Document 8K088X04 R5.01
Notes
This is a read only field that
displays the name of the Analog
Code Table only when configured
in Channel – Analog Code Table
PL/DPL Assignments window.
• W > R: Wireline has priority over
Repeater
• R > W: Repeater Rx has priority
over Wireline
• R = W: Repeater Rx and
Wireline have equal priority.
Whichever occurs first takes and
maintains PTT control.
Any value entered that is not an
increment of 10 is rounded up to
the next valid value.
Any value entered that is not an
increment of 10 is rounded up to
the next valid value.
This is also known as hang-time.
