Status Report - Futurecom PDR8000 Programming Manual

Field Name
Heartbeat Period 5-55
(sec)
Booster Pack
Booster Pack
OFF
Connected
ON
Booster Pack ACTIVE
State
Ambient Celsius
Temperature
Power Amplifier Celsius
Temperature
Note: Fields in Booster Pack group are populated only when connected to PDR8000. Not applicable to
Rackmount PDR8000 with 50W PA option.
Note: In the Options/Units column, the option in bold text indicates the default value.
S R
TATUS EPORT
Field Name Options /
Get Status
Save Status
Clear All
2022-08-25
Options /
Units
Periodicity of Host Heartbeats
at which the PDR8000
expects a heartbeat from the
host.
ON: Booster Pack connected
to the PDR8000.
OFF: Booster Pack not
connected
ACTIVE: When the Booster
pack is connected and
powered up.
Booster Pack Internal
temperature.
RF Power Amplifier
temperature.
Units
Gets the PDR8000 Status Report
Saves the Status Report as text file
Clears the contents
®
PDR8000 Portable Digital Repeater Programming Guide
Description
Description
Document 8K088X04 R5.01
Notes
Provided to PDR8000 by the host
when PDR8000 wireline interface is
set to DFSI.
The PDR8000 detects the Booster
Pack when connected via the AUX
Port.
Read only
For Hardware Rel.4-Booster pack is
connected and of matching frequency
band.
Read Only
Read Only
Notes
Page 68 of 86
