Field Name
Rx Freq. (MHz) MHz
Tx Freq. (MHz) MHz
Tx Pwr (dBm) 30-43 dBm
30.00 dBm
Tx Pwr (Watts) 1-20 Watts
1.0 Watts
NAC Table Index 1-64
NAC Code Table Link, Maximum
10 alphanumeric
characters
ANA Table Index 1-64
2022-08-25
Options /
Units
Receive frequency for the current
channel.
Transmit frequency for the current
channel.
Specifies the transmit power at
the Power Amplifier output of the
PDR8000
Specifies the transmit power at
the Power Amplifier output of the
PDR8000 in (W)
Identifies which of the 64 possible
Access Code Tables applies to
the current channel.
Identifies by name and provides a
link to open the Channel – Access
Code Table ASTRO NAC
Assignments window associated
with the current channel.
Identifies which of the 64 possible
PL/DPL Tables applies to the
current channel.
®
PDR8000 Portable Digital Repeater Programming Guide
Description
Document 8K088X04 R5.01
Notes
When Hardware Platform is set to
Satellite Tx or channel mode to
Simplex, this field is read only and
is disregarded.
Must equal Channel-0 Base
Frequency plus an integer
multiple of Channel No. Spacing
as defined in Frequency Band
Configuration window.
Must also match the PSU
Transmit Frequency.
When Hardware Platform is set to
Satellite Rx, this field is read only
and is disregarded.
Must equal Channel-0 Base
Frequency plus an integer
multiple of Channel No. Spacing
as defined in Frequency Band
Configuration window.
Must also match the PSU Receive
Frequency.
When Hardware Platform is set to
Satellite Rx, this field is read only
and is disregarded.
Read only
This is a read only field that
displays the name of the Access
Code Table only when configured
in Channel – Access Code Table
ASTRO NAC Assignments
window.
