Futurecom PDR8000 Programming Manual page 60

Field Name Options / Units
Tx PL/DPL
Selected by Last
Received Rx
PL/DPL
Enabled
Disabled
Tx PL/DPL 1-30 min
selected by Last
5 min
Rx PL/DPL
Duration
Multi-PL/DPL Maximum 14 pairs
Table
Enabled Checkbox
Rx PL/DPL STE deg/DPL
Rx PL/DPL PL: 67.0-254.1
DPL: d-023-d-754
2022-08-25
®
PDR8000 Portable Digital Repeater Programming Guide
Description
Specifies how Tx PL/DPL is selected for
transmitting the infrastructure audios.
Enabled: When the Tx PL/DPL Selected by
Last Rx PL/DPL Duration has not expired,
the Tx PL/DPL is selected according to
following rules:
For Multi-NAC operation, Tx PL/DPL is set
to the programmed Tx PL/DPLL from the
row in the Multi-NAC table where Rx
PL/DPL is equal to the last received Rx
PL/DPL.
Disabled: or Tx PL/DPL Selected by Last
Rx NAC Duration has expired, the Tx
PL/DPL is set to the programmed Tx NAC
from the first row in the Multi-PL/DPL Table.
Defines how long the last Rx PL/DPL is
used for transmissions after the last
received call. Each received call restarts the
timer.
Defines up to 14 Rx and Tx Network Access
Code pairs for the specified Analog Code
Table.
Identifies if current row of the table is
enabled for use.
Analog PSU PL/DPL STE-Squelch Tail
Elimination – must be programmed to match
the PSU.
Defines receive PL/DPL.
Document 8K088X04 R5.01
Notes
This field is
accessible only
when Tx
PL/DPL
Selected By
Last Rx PL/DPL
is Enabled.
If Rx PL/DPL
Operation is set
to Multi-PL/DPL,
all rows in the
Multi-PL/DPL
table are
accessible. If
Rx PL/DPL
Operation is not
set to Multi-
PL/DPL, only
the first row in
the Multi-
PL/DPL table is
accessible.
Page 60 of 86
