Futurecom PDR8000 Programming Manual page 67

Field Name
Squelch OFF dB SINAD
Threshold
Temp Celsius
PA Temp Celsius
RSSI ON dBm
Threshold
Synthesizer Locked
Out of Lock
DC Voltage Normal
High
Low
Antenna Switch Normal
Reverse
DFSI*
Host IP Address 0.0.0.0
Host Control Port Max 65535
Host Voice Port Max 65535
2022-08-25
Options / Description
Units
Sets the Squelch OFF
Threshold.
PDR8000 internal
temperature
RF Power Amplifier
temperature
Sets the RSSI ON Threshold
Current state of the
Synthesizer
DC Voltage
Current antenna switch
position
Shows the IP Address of the
DFSI Host
UDP Port at which the fixed
station supplies the Control
Service.
UDP Port at which the fixed
station supplies the Voice
communication.
®
PDR8000 Portable Digital Repeater Programming Guide
Affects Analog Mode only.
Typical recommended setting
OFF: 10dB SINAD.
If this field is temporarily modified in
Monitoring Window for "tuning" the
PDR, however leaving the Monitoring
Screen will result in reverting to the
previously programmed/saved values
Read only
Read only
Typical recommended setting
Is -115 dBm.
If this field is temporarily modified in
Monitoring Window for "tuning" the
PDR, however leaving the Monitoring
Screen will result in reverting to the
previously programmed/saved values
Read only
Read Only
Read Only
IPv4 address for the DFSI host.
Provided to PDR8000 by the host
when PDR8000 wireline interface is
set to DFSI.
Provided to PDR8000 by the host
when PDR8000 wireline interface is
set to DFSI.
Provided to PDR8000 by the host
when PDR8000 wireline interface is
set to DFSI.
Document 8K088X04 R5.01
Notes
Page 67 of 86
