U F
SING THE UTURECOM
The Futurecom Repeater Configurator (FRC) can be used off-line to review, modify and save
new personality templates (dpd) files.
V PDR8000 P
IEWING
Run the Futurecom Repeater Configurator (FRC).
Select File → DPD Files (Templates) → Load DPD File and specify the dpd file location and
name when prompted.
M PDR8000 P
ODIFYING
Once a dpd file is successfully opened (as described in the previous section), the dpd settings
are available for reviewing and modification off-line.
S PDR8000 P
AVING
For saving Personality files, ensure the Futurecom Repeater Configurator (FRC) is On-Line.
Power up the PDR8000. Connect the PDR8000 to the PC running the Futurecom Repeater
Configurator (FRC).
After editing the personality setting, the dpd file can be saved by selecting File → DPD Files
(Templates) → Save DPD File and specifying a new or the same dpd file name and location.
The User can select the Deployments to be saved in the Pop-up window as shown below.
2022-08-25
R C
EPEATER ONFIGURATOR
F
ERSONALITY ILES
F
ERSONALITY
F
ERSONALITY ILES
®
PDR8000 Portable Digital Repeater Programming Guide
(FRC) O
ILES
Document 8K088X04 R5.01
-L
FF INE
Page 18 of 86
