This message indicates that the program created a new file with the same name as the old file,
but with the suffix "_v2_to_v4_updated.dpd"
For example, if the original file was named: Myfile.dpd
The upgraded file would be: Myfile_v2_to_v4_updated.dpd
After closing this message, it will immediately load the new upgraded dpd file.
W S
RITING ELECTED
If any changes are made while reviewing the personality data of a PDR8000 (On-Line), the
fields containing changes are shaded in green (if the changes are valid). If the changes are not
valid, the fields will be marked red and the new settings cannot be saved to the repeater.
After making the necessary changes to all the settings on the various Futurecom Repeater
Configurator (FRC) screens, the new personality can be saved to the PDR8000 by executing
any of the following:
12. PDR → Save Changes to PDR Repeater
13. OR
14. F4
15. OR
16. PDR → EEprom Maintenance (Ctrl+E) → Changes → PDR
17. OR
18. Click on the EEprom Maintenance Icon → Changes → PDR
Reset the repeater (after the changes are saved) in order to ensure the changes are in effect.
Resetting of the PDR8000 can be done by executing any of the following methods:
•
PDR → Reset PDR Repeater
•
OR
•
F3
•
OR
•
EEprom Maintenance → Reset Repeater
When the PDR8000 personality has been changed and the changes are not causing any
detected errors, the EEprom maintenance icon is flashing yellow. Clicking on the icon opens the
EEprom screen which offers the options of saving the changes to the PDR8000 and resetting
the PDR8000. If the data changes contain errors, the EEprom icon is flashing red and the
screens containing conflicting data will be marked with a red exclamation mark. In this case, the
changes cannot be written to the PDR8000 EEPROM until the errors are eliminated.
