Futurecom PDR8000 Programming Manual page 65

Field Name
TalkGroup
Subscriber
ID(Decimal)
Transmitter Activity
Tx Idle
Active
Tx Source Inbound
Outbound
Tx NAC
Tx PL/DPL
TalkGroup
Tx Power Alarm
P25 Rx Modem Test
BER Rx Test NO
YES
BER %
BERm %
Infrastructure Activity
Link State Fail
Pass
Link Type V.24
DFSI
Rx Idle
Active
2022-08-25
Options / Description
Units
Displays the Subscriber
Talkgroup ID
Displays the Subscriber ID in
decimal format
Specifies the Transmitter
Activity
Displays if the PDR8000 is
receiving from the Subscriber
or transmitting on V.24 Link.
Displays the NAC transmitted
to the Subscriber
Displays the PL/DPL received
from the Subscriber
PDR8000 activates the Txt
power alarm if the difference
in the measured RF Tx power
and programmed Tx power
exceed this threshold.
Bit Error Rate P25 Rx Modem
Test control
Current Bit Error Rate
Mean Bit Error Rate
Current State of the Wireline
Interface Link
Current Link type
Specifies the Link Activity
®
PDR8000 Portable Digital Repeater Programming Guide
User configurable- available in-
Service Mode only
Service Mode only
Service Mode only
Read only
Read only
Read only
Document 8K088X04 R5.01
Notes
Page 65 of 86
