Futurecom PDR8000 Programming Manual page 42

Field Name
RT/RT
Configuration
Packet Data
Repeat Packet
Data
Wireline Data Drop
Out Delay
In-Cabinet Repeat
Fallback In-
Cabinet Repeat
Fallback
Determination
Time
Local PTT Test
Tone
2022-08-25
Options /
Units
Disabled Disabled: PDR8000 cannot be
Enabled used in RT/RT configuration.
Enabled: PDR8000 used in RT/RT
(back-to-back) configuration.
When Disabled Data is sent to
Disabled
Infrastructure. When Enabled Data
Enabled
is repeated locally.
0 sec Specifies the duration of the
transmission of idle packets
0-255 sec
following the transmission of an
infrastructure originated data
packet.
Disabled Disabled: when the link failure is
detected, the PDR8000 does not
Link Failure
automatically activate its local
repeat capabilities.
Link Failure or
Timer
Link Failure: when the link is
disconnected, the PDR8000 does
automatically activate its local
repeat capabilities.
Link Failure or Timer: when the
link is disconnected, or the Fallback
Determination Time expires, then
the PDR8000 does automatically
activate its local repeat capabilities.
180ms Amount of time the PDR8000 waits
for an outbound payload from the
50-10000ms
infrastructure after sending an
inbound payload via the wireline
interface.
Check box When disabled, pushing the Local
PTT button transmits an RF carrier
on the active channel.
When enabled, pushing the Local
PTT button transmits a 1 kHz test
tone on the active channel.
®
PDR8000 Portable Digital Repeater Programming Guide
Description
Document 8K088X04 R5.01
Notes
This field is enabled when
Wireline Interface is set to
V.24.
Packet Data is not applicable
to DFSI deployments.
A value of 0 means disabled.
This field is not applicable to
channels in Half Duplex or
Simplex Mode.
When Wireline Interface is set
to None, this field must be set
to Disabled.
This timer is used when the
Fallback In-Cabinet Repeat is
set to Link Failure or Timer.
This field is disregarded when
Fallback In-Cabinet Repeat is
set to Disabled or Link Failure.
Page 42 of 86
