Repeater
Repeater
Operation
Repeater Gate
Update
Repeater Gate
Startup State
Start up
Start on Last
Active Channel
Startup Channel
BSI Interval
Astro Fade
Tolerance
P25 Frame Sync
Detection Timer
2022-08-25
Base Specifies whether station is
operating as a Base mode or
Repeater
Repeater mode.
Disabled Specifies how the station
determines its state after a reset.
Enabled
Enabled: the station comes up in
the state last requested by the
console (Repeater Set Up or
Repeater Knocked Down)
Disabled: the station comes up in
the state specified by the Repeater
Gate Startup State field.
Repeat Set Up Specifies the station's state after a
Repeat Knocked reset: Repeat Set Up or Repeater
Down Knocked Down
Disabled Specifies if the PDR800 starts on
the last active channel after a reset.
Enabled
1-64 Specifies the channel to which
PDR8000 is set after a reset.
1
1-60 minutes Specifies the time interval at which
the FCC assigned station call sign
30 min
is broadcast.
1-3 frames Specifies the number of missed
frames before ASTRO message is
3
considered terminated.
30-255 ms Specifies for how long the
PDR8000 digital decoder waits for
100 ms
P25 digital signaling (Frame Sync)
before it assumes that the received
signal is analog.
®
PDR8000 Portable Digital Repeater Programming Guide
Base- local repeat is
unavailable (Full Duplex, Half
Duplex and Simplex are
supported)
Repeater- local repeat
available on Full Duplex
channels only (depending on
Gate Parameters)
This field is only accessible
when Repeater Operation is
set to Repeater.
This field is only accessible
when Repeater Operation is
set to Repeater AND Repeater
Gate Update is Disabled.
This field is ignored when
Startup on Last Active
Channel field is set to
Enabled.
