DFSI*
Fixed Station IP
Address
Fixed Station Port
Control Retry
Timer (ms)
Control Attempt
Limit
Connectivity Loss
Limit
DFSI IP Subnet
Fixed Station
Voice Conveyance
Port
Note: In the Options/Units column, the option in bold text indicates the default value.
* Fields in this group are applicable and editable only when Wireline Interface field is set to DFSI
C C
HANNEL ONFIGURATION
The V.24 wireline interface to PDR8000 is a full-duplex link, able to send and receive
information at the same time. However, there are different configurations for the RF aspect of a
PDR8000 that govern whether the PDR8000 can both Transmit and Receive on the RF channel
at the same time (full-duplex), or whether only one side of the RF channel is serviced at once
(half-duplex). This (Full/Half) Duplex mode is configurable on a per-channel basis.
Analog, Digital and Mixed-mode channels are supported for full-duplex operation only.
2022-08-25
0.0.0.0- Standard IP address for the fixed
255.255.255.254 station. This value shall match
what's programmed in the DFSI
host to connect to this station.
0-65535 UDP Port at which the fixed station
supplies the Control Service
50006
200-2000 Retry period for control messages.
500 This period shall be used for all
control messages except for
Heartbeat and Acknowledgements.
Maximum number of attempts for
1-10
control messages
3
This number shall be used for all
control messages except for
Heartbeat and Acknowledgements
1-10 Maximum number of heartbeat
losses to allow
2
Standard subnet mask usually set
255.x.x.x
to 255.255.255.0 for C class
network
2-65534 UDP Port at which RTP traffic is
conveyed to the PDR8000. The
51000
port number shall be even
®
