Field Name
Deployments order on the
PDR8000 Display
Deployment Information
Name
Enabled
Copy Deployment
Reset Deployment
Reset Order
Update Deployments
Close
If the user clicks "Close" and no modifications have been made to the deployment order or any
deployment name/enable status, the dialogue will close. If any of the aforementioned changes
have been made, the user will be prompted with this message:
Selecting "Yes" will apply the changes and close the Deployment Configuration dialogue.
Selecting "No" will not apply the changes and close the Deployment Configuration dialogue.
Selecting "Cancel" will not apply the changes, but not close the Deployment Configuration
dialogue.
Upon clicking 'Update Deployments' user is prompted to confirm the changes.
2022-08-25
PDR8000
Options /
Units
List of Deployments and theirs Status
Deployment name – up to 16 max
characters
Deployment enabled when checkbox is
checked
Allows to copy Deployment X
configuration to Deployment Y selected
from the list.
Resets the currently selected
Deployment to Factory default.
Resets to factory order.
Update the Deployments as Configured
Prompts to confirm the changes made
to the Deployment before the window
closes.
Document 8K088X04 R5.01
®
Portable Digital Repeater Programming Guide
Description Notes
Enabled or Disabled
Deployment status
is displayed in the
list of Deployments.
Deployment 1 is
always enabled
