U F
SING THE UTURECOM
To use the Futurecom Repeater Configurator (FRC) on-line the following is required:
1 Futurecom Repeater Configurator (FRC) software installed on the PC.
2 Powered up PDR8000.
3 Programming cable (USB cable directly connected to the PDR8000).
S C
ETTING UP OMMUNICATIONS WITH THE
1. Ensure the USB cable is plugged into your PC and connected to the USB port on the
PDR8000.
2. Ensure the PDR8000 is powered up. Check the LED Display on the panel.
3. The 'Power' LED and 'DC /Battery' LED should be green.
4. On the splash screen, select PDR8000 – by clicking the labeled button on the bottom
right.
5. On the Futurecom Repeater Configurator (FRC) click on 'Ports' under 'COM Options'
menu.
6. Check if the 'Futurecom USB modem' is displayed on the Com port field.
7. If the com port display is blank, check the USB connection or change the USB Port on
the computer.
COM O : P
PTIONS
Field Name
COM Port N/A
R PDR8000 E
EADING THE
The Electronic Label of the PDR8000 contains information regarding the firmware currently
loaded in the PDR8000, the hardware model and serial number.
To read the PDR8000 Electronic Label, open the Hardware/Software Information window in the
Futurecom Repeater Configurator (FRC).
The electronic label can be read either on-line or by loading a previously saved epr or dpd file.
The Electronic Label is also stored in the dpd file, even though the information contained in it
does not overwrite the electronic labels of the PDR8000s during 'cloning'.
Note:
An epr file contains the personality and calibration data of a specific PDR8000 unit. A dpd file
contains the personality settings of a PDR8000 unit. Used for 'cloning'.
2022-08-25
R C
EPEATER
ORTS
Range Description
Drop down list of ports available
when connecting directly to the
PDR8000 USB Port.
LECTRONIC
®
PDR8000 Portable Digital Repeater Programming Guide
(FRC) O
ONFIGURATOR
PDR8000
L
ABEL
Document 8K088X04 R5.01
-L
N INE
Notes
Page 20 of 86
