Futurecom PDR8000 Programming Manual page 55

Field Name Options / Units
Multi-NAC Table Maximum 8 pairs
Enabled Checkbox
Rx NAC (hex) 000-FFF
Tx NAC (hex) 000-FFF
Error report:
Delete
Apply ACT # xx
to CH # yy
Update Access
Code Table # xx
Exit
Within each digital Access Code Table is a setting for the Rx NAC Operation mode to be
utilized by channels pointing to this table. The four modes of Rx NAC Operation are:
1. Normal
2. Receiver Monitor $F7E
3. Community Repeater $F7F
4. Multi NAC
Within each digital Access Code Table, exists a Multi-NAC table defining the particular NAC
values used to govern squelch operation on the configured channel. The table consists of 8
rows, having an Rx NAC and corresponding Tx NAC value (each value 0-$FFF). In most
cases, only one row of values is used. If the configured 'Rx NAC Operation' operation is
selected for Multi-NAC ; then all 8 rows are available for use (each row can be
enabled/disabled for use during configuration.)
2022-08-25
®
PDR8000 Portable Digital Repeater Programming Guide
Description
Defines up to eight Rx and Tx Network
Access Code pairs for the specified Access
Code Table.
Identifies if current row of the table is
enabled for use.
Defines receive ASTRO Network ID.
Defines transmit ASTRO Network ID
Displays any warnings or errors related to
the creation of Rx/Tx NAC pairs in the Multi-
NAC table.
Pressing this button deletes all entries in this
row of the table and shifts all rows beneath
up by one row.
Clicking on this tab applies the NAC values
ACT # xx to CH yy
In the "Channel Configuration' Channel # yy
Updates the Access Code Table ACT# xx in
the "Channel Configuration"
Exits the Table
Document 8K088X04 R5.01
Notes
If Rx NAC
Operation is set
to Multi-NAC, all
rows in the
Multi-NAC table
are accessible.
If Rx NAC
Operation is not
set to Multi-
NAC, only the
first row in the
Multi-NAC table
is accessible.
Page 55 of 86
