Futurecom PDR8000 Programming Manual page 50

Field Name
Monitor Before Disabled
Data Tx Enabled
Tx Inhibit Disabled
Enabled
Base Station ID Maximum 20
alphanumeric
characters
(uppercase
letters only)
Sq. On Tr 4-28 dB SINAD
15 dB
Sq. Off Tr 3-25 dB SINAD
10 dB
ON/OFF Trigger RSSI
Squelch
Sq &RSSI
Bandwidth Set 1
Set 2
Set 3
Note: In the Options/Units column, the option in bold text indicates the default value.
2022-08-25
Options /
Units
Disabled: PDR8000 does not
monitor or notify the infrastructure
of any co-channel users.
Enabled: PDR8000 monitors the
Rx channel for co-channel users
and notifies the infrastructure
Disabled: PDR8000 transmits on
the selected channel.
Enabled: PDR8000 does not
transmit if this field enabled.
Used for automatic, periodic, over-
the-air transmission of the
PDR8000's call sign.
If empty BSID will not be
transmitted.
Squelch ON Threshold
Squelch OFF Threshold
Analog Mode – any ON/OFF
trigger can be selected.
Digital Mode – RSSI only allowed.
Mixed Mode – RSSI only allowed.
Selects the FM channel bandwidth
(12.5kHz or 25KHz) as
programmed in the 'Frequency
Band Setup' menu.
®
PDR8000 Portable Digital Repeater Programming Guide
Description
Document 8K088X04 R5.01
Notes
Enabled: If a co-channel user is
detected, the PDR8000 will notify
the infrastructure (wireline) every
5 seconds. The PDR8000 will not
transmit data once it receives this
message. When co-channel
activity stops, the PDR8000 will
again notify the infrastructure
(wireline). The PDR8000 will
resume data transmission once it
receives this message.
Assigned on a per channel basis,
allowing pre-configuration of
different call signs on channels
that are used for different
geographical deployments.
When Trigger is selected as
Squelch
When Trigger is selected as
Squelch
Squelch is invalid setting in Digital
or Mixed Mode PDR8000
Channels.
See 'Frequency Band
Configuration' Screen.
Page 50 of 86
