Booster Pack Specifications
General Specifications
Dimensions: Width / Height / Depth
DC Current Drain
Operating Temperature, Full Power setting;
At 50% Transmit Duty Cycle with case closed
At 100% Transmit Duty Cycle with case open
External Connectors
Equipment Type Acceptance
Transmitter Specification
2021-11-0
488 mm (19.2") x 386 mm (15.2") x 185 mm (7.3")
Weight
23.2 lbs. / 10.5kg
AC Supply Voltage
100V AC to 240V AC, 47Hz to 63Hz
AC Current at 120V AC
4.0A
DC Supply Voltage
13.8V DC -15%/+20%
Standby/Receive
0.7A
Transmit
14.3A
-30°C to 55°C
-30°C to 50°C
RF Input
N female, with Dustcap
RF Output
N female, with Dustcap
AC Input
powerCON TRUE1, NAC3MPX, with Sealing Cover
DC Input
LEMO push pull, EGL.2K.302.CLA, with Dustcap
AUX
LEMO push pull, EGG.1K.308.CLL, with Dustcap
Ground
Stainless steel stud, 0.5" long with 10-32 thread
CWWDSDTV100XX
FCC
7291A-
Industry Canada
DSDTV100XX
Frequency Bands
PDR8000® Portable Digital Repeater Programming Guide
VHF
UHF
CWWDSDTUL50
CWWDSDTUH50
VHF
UHF
136-174 MHz
380-430 MHz
8K088X04 R5.00
700/800
MHz
CWWDSDTJK50
700 MHz
800 MHz
764-776 MHz
851-869 MHz
Page 81 of 98
