1.2 System Features

The following views of the system display the main features. Refer to
specifications.

Front View

800 W Power Supplies
(PSU1, PSU2)
Control Panel UID Button
Dry Contact
600 W Power Supplies
(PSU1, PSU2)
Feature Description
Control Panel Front control panel with LEDs and buttons (see
Two redundant power supply modules (PSU1 on top, PSU2 below)
Power Supplies SYS-211E-FRN13P: 800 W AC 100-127 Vac, 60-50 Hz, 10A , 200-240 Vac, 60-50 Hz, 5.5 A
SYS-211E-FRN13P/31DS: 600 W DC -44 -65 Vdc, 18-10 A (x2)
UID Button Button will turn on/off the system
Dry Contact One dry contact (with four sets)
One RJ45 GbE LAN port (IPMI shared on LAN port 1)
LAN Ports
12 SFP28 25 GbE LAN ports* (IPMI shared on LAN port 10)
USB Ports Two USB 3.0 ports
GNSS + 1PPS** Five SMA 1pps and GNSS connectors
VGA Port One video port
Server Handle Two (left and right) handles supporting server removal
*This product is intended to be used with a UL Listed Optical Transceiver product, Rated
DC3.3 V, Laser Class 1.
**The antenna ports do not route to any external antennas or plants.
Shared IPMI LAN Port
USB Ports GNSS + 1PPS
Figure 1-1. Front View: SYS-211E-FRN13P
Figure 1-2. Front View: SYS-211E-FRDN13P
System Features: Front
10
Chapter 1: Introduction
Appendix C
1
2
VGA Port Shared IPMI LAN Port
SFP28 25 GbE LAN Ports
Control Panel for details)
for additional
Server Handle
