Operation
6.7
The optoCONTROL 1200/1200/90/1201 enables individual setting of the threshold
(for the location of the threshold potentiometer).
ON
OFF
Fig. 13 Switching output optoCONTROL 1200/1200/90/1201
optoCONTROL 1200/1201

Switching Output

5 V
O V
The switching threshold of the limit output is freely
adjustable via a potentiometer and is activated
when limit values are exceeded or not
see Fig. 13:
- PNP active if light quantity below limit
10 V
- NPN active if light quantity above limit
value, see 6.3, see 6.4
reached,
