Installation and Assembly
24 (.94)
Light source
B
M4 x 5
M5 x 8
3
(.12)
Fig. 7 Dimensional drawing ODC 1200/90, dimensions in mm
optoCONTROL 1200/1201
12 (.47)
Laser light
max. 2500 (98.43)
4 (.16)
4 (.16)
16
(.63)
24 (.94)
12 (.47)
Receiver
B
M4 x 5
M5 x 8
16
(.63)
Model
ODC1200/90-2
ODC1200/90-5
ODC1200/90-10 10 x 2 (.39 x .08) 10 x 0.3 (.39 x .01)
ODC1200/90-16 16 x 2 (.63 x .08) 16 x 0.3 (.63 x .01)
.
3
(.12)
Aperture dimensions
(A x B) in mm
Light source
2 x 2 (.08 x .08)
5 x 2 (.20 x .08)
Receiver
2 x 0.3 (.08 x .01)
5 x 0.3 (.20 x .01)
