Installation and Assembly
Housing
ODC1200-...-T
ODC1200-...-R
ODC1200-90-...-T
ODC1200-90-...-R
ODC1201-...-T
ODC1201-...-R
Housing
ODC1200-...-T
ODC1200-...-R
ODC1200-90-...-T
ODC1200-90-...-R
ODC1201-...-T
ODC1201-...-R
optoCONTROL 1200/1201
Push through
Screw
length
ISO 4762 - A2
mm
24
M4
24
M4
24
M4
24
M4
29
M4
29
M4
Screw-in depth
Minimum
Maximum
mm
mm
5
1
5
1
5
1
5
1
5
1
5
1
Bolt connection
Washer
Tightening torque
per screw
ISO 7089 - A2
µ = 0.12
Nm
A4.3
2
A4.3
2
A4.3
2
A4.3
2
-
2
-
2
Direct fastening 1
Screw
Tightening torque
per screw
ISO 4762 - A2
µ= 0.12
Nm
M4
3
M4
3
M4
3
M4
3
M4
3
M4
3
