Operation
Example with offset
Analog signal with free beam 10
With 100 % shading the offset is 0.02 V.
x [mm] =
x [mm] =
x [mm] = 5 mm
optoCONTROL 1200/1201
With free beam, set the analog signal to 10.02 V.
MR [mm] * (10 V + offset - V
10 V
10 mm * (10 V + 0.02 V - 5.02 V)
10 V
V, see Fig. 15.
)
OUT
