Installation und Montage
12
Lichtquelle
B
M4 x 5
M5 x 8
3
Abb. 7 Maßzeichnung ODC 1200/90, Abmessungen in mm
optoCONTROL 1200/1201
24
Laserlicht
max. 2500
4
16
24
12
Empfänger
B
M4 x 5
M5 x 8
4
16
3
Blendenmaße
(A x B) in mm
Modell
Sender Empfänger
ODC1200/90-2
2 x 2
ODC1200/90-5
5 x 2
ODC1200/90-10
10 x 2
ODC1200/90-16
16 x 2
2 x 0,3
5 x 0,3
10 x 0,3
16 x 0,3
Seite 19
