Parameter
Generated Active Energy L3
Total Active Energy generated
Generated Inductive Reactive Energy L1
Generated Inductive Reactive Energy L2
Generated Inductive Reactive Energy L3
Total Inductive Reactive Energy Generated
Generated Capacitive Reactive Energy L1
Generated Capacitive Reactive Energy L2
Generated Capacitive Reactive Energy L3
Total Capacitive Reactive Energy generated
Generated Reactive Energy L1
Generated Reactive Energy L2
Generated Reactive Energy L3
Total Reactive Energy generated
Generated Apparent Energy L1
Generated Apparent Energy L2
Generated Apparent Energy L3
Total Apparent Energy generated
Parameter
Consumed Active Energy L1
Consumed Active Energy L2
Consumed Active Energy L3
Total Active Energy Consumed
Consumed Inductive Reactive Energy L1
Consumed Inductive Reactive Energy L2
Consumed Inductive Reactive Energy L3
Total Inductive Reactive Energy consumed
Consumed Capacitive Reactive Energy L1
Consumed Capacitive Reactive Energy L2
Consumed Capacitive Reactive Energy L3
Total Capacitive Reactive Energy consumed
Consumed Reactive Energy L1
Consumed Reactive Energy L2
Consumed Reactive Energy L3
Total Reactive Energy consumed
Consumed Apparent Energy L1
Consumed Apparent Energy L2
Consumed Apparent Energy L3
Total Apparent Energy consumed
Instruction Manual
Table 18 (Continued): Modbus Memory Map: Energy variables (Table 1)�
Total Energies
Table 19: Modbus Memory Map: Energy variables (Table 2)�
Energies per Tariffs
Format Address
Uint [64] 56C - 56D - 56E - 56F
Uint [64] 570 - 571 - 572 - 573
Uint [64] 574 - 575 - 576 - 577
Uint [64] 578 - 579 - 57A - 57B
Uint [64] 57C - 57D - 57E - 57F
Uint [64] 580 - 581 - 582 - 583
Uint [64] 584 - 585 - 586 - 587
Uint [64] 588 - 589 - 58A - 58B
Uint [64] 58C - 58D - 58E - 58F
Uint [64] 590 - 591 - 592 - 593
Uint [64] 594 - 595 -596 - 597
Uint [64] 598 - 599 - 59A - 59B
Uint [64] 59C - 59D - 59E - 59F
Uint [64] 5A0 - 5A1 - 5A2 - 5A3
Uint [64] 5A4 - 5A5 - 5A6 - 5A7
Uint [64] 5A8 - 5A9 - 5AA - 5AB
Uint [64] 5AC - 5AD - 5AE - 5AF
Uint [64] 5B0 - 5B1 - 5B2 - 5B3
Tariff 1
Format Address
Uint [64] 5B4 - 5B5 - 5B6 - 5B7
Uint [64] 5B8 - 5B9 - 5BA - 5BB
Uint [64] 5BC - 5BD - 5BE - 5BF
Uint [64] 5C0 - 5C1 - 5C2 - 5C3
Uint [64] 5C4 - 5C5 - 5C6 - 5C7
Uint [64] 5C8 - 5C9 - 5CA - 5CB
Uint [64] 5CC - 5CD - 5CE - 5CF
Uint [64] 5D0 - 5D1 - 5D2 - 5D3
Uint [64] 5D4 - 5D5 - 5D6 - 5D7
Uint [64] 5D8 - 5D9 - 5DA - 5DB
Uint [64] 5DC - 5DD - 5DE - 5DF
Uint [64] 5E0 - 5E1 - 5E2 - 5E3
Uint [64] 5E4 - 5E5 - 5E6 - 5E7
Uint [64] 5E8 - 5E9 - 5EA - 5EB
Uint [64] 5EC - 5ED - 5EE - 5EF
Uint [64] 5F0 - 5F1 - 5F2 - 5F3
Uint [64] 5F4 - 5F5 - 5F6 - 5F7
Uint [64] 5F8 - 5F9 - 5FA - 5FB
Uint [64] 5FC - 5FD - 5FE - 5FF
Uint [64] 600 - 601 - 602 - 603
Units
Wh
Wh
varhL
varhL
varhL
varhL
varhC
varhC
varhC
varhC
varh
varh
varh
varh
VAh
VAh
VAh
VAh
Units
Wh
Wh
Wh
Wh
varhL
varhL
varhL
varhL
varhC
varhC
varhC
varhC
varh
varh
varh
varh
VAh
VAh
VAh
VAh
