7�3�7�- QUALITY EVENT AND DISTURBANCE COUNTERS
Function 0x04: register readout, is used for these variables.
7�3�8�- OTHER DEVICE PARAMETERS
Function 0x04: register readout, is used for these variables.
Parameter
Device ID number
ID number of Slot 1 expansion module
ID number of Slot 2 expansion module
Device serial number
Serial number of Slot 1 expansion module
Serial number of Slot 2 expansion module
Current tariff
Firmware version (part 1)
Firmware version (part 2)
Firmware version revision
Device Model
Firmware version (part 1) of Slot 1 expansion module
Firmware version (part 2) of Slot 1 expansion module
Revision of Slot 1 expansion module firmware version
Slot 1 expansion module device model
Firmware version (part 1) of Slot 2 expansion module
Firmware version (part 2) of Slot 2 expansion module
Revision of Slot 2 expansion module firmware version
Slot 2 expansion module device model
90
Table 25: Modbus Memory Map: Quality event and disturbance counter�
Parameter
Overvoltage meter L1
Overvoltage meter L2
Overvoltage meter L3
Gap meter L1
Gap meter L2
Gap meter L3
Voltage interruption meter L1
Voltage interruption meter L2
Voltage interruption meter L3
Table 26: Modbus Memory Map: Other device parameters�
Format Address
Uint [16] 11C6
Uint [16] 11C7
Uint [16] 11C8
Uint [16] 11CB
Uint [16] 11CC
Uint [16] 11CD
Uint [16] 11D0
Uint [16] 11D1
Uint [16] 11D2
Format
Uint [32]
Uint [32]
Uint [32]
364C - 364D -364E -364F -3650 -3651
String
3653 - 3654 -3655 -3656 -3657 -3658
String
365A - 365B -365C -365D -365E -365F
String
Uint [16]
Uint [16]
Uint [16]
Uint [16]
String
Uint [16]
Uint [16]
Uint [16]
String
Uint [16]
Uint [16]
Uint [16]
String
line-CVM-D32
Units
-
-
-
-
-
-
-
-
-
Address
35E8-35E9
35EA-35EB
35EC-35ED
-3652
-3659
-3660
59EC
C288
C289
C28A
C28C-C28D
C292
C293
C294
C296-C297
C29C
C29D
C29E
C2A0-C2A1
