Circutor Line-CVM-D32 Instruction Manual page 14

2�- Insert the expansion connector and fastening clips into one of the devices (
3 �- Connect both devices and fasten them by pushing the front clips down (
14
For correct installation of all devices, please refer to the instruction manual for the
different models:
M231B01-03-xxx: Instruction Manual for line-EDS devices.
M239B01-03-xxx: Instruction Manual for line-M expansion modules.
Figure 8: Installation step 1�
Figure 9: Installation step 2�
Figure 10: Installation step 3�
line-CVM-D32
).
Figure 9
).
Figure 10
Instruction Manual
