Circutor Line-CVM-D32 Instruction Manual page 80

Parameter
Generated Active Energy L1
Generated Active Energy L2
Generated Active Energy L3
Total Active Energy generated
Generated Inductive Reactive Energy L1
Generated Inductive Reactive Energy L2
Generated Inductive Reactive Energy L3
Total Inductive Reactive Energy generated
Generated Capacitive Reactive Energy L1
Generated Capacitive Reactive Energy L2
Generated Capacitive Reactive Energy L3
Total Capacitive Reactive Energy generated
Generated Reactive Energy L1
Generated Reactive Energy L2
Generated Reactive Energy L3
Total Reactive Energy generated
Generated Apparent Energy L1
Generated Apparent Energy L2
Generated Apparent Energy L3
Total Apparent Energy generated
Parameter
Consumed Active Energy L1
Consumed Active Energy L2
Consumed Active Energy L3
Total Active Energy consumed
Consumed Inductive Reactive Energy L1
Consumed Inductive Reactive Energy L2
Consumed Inductive Reactive Energy L3
Total Inductive Reactive Energy consumed
Consumed Capacitive Reactive Energy L1
Consumed Capacitive Reactive Energy L2
Consumed Capacitive Reactive Energy L3
Total Capacitive Reactive Energy consumed
Consumed Reactive Energy L1
Consumed Reactive Energy L2
Consumed Reactive Energy L3
Total Reactive Energy consumed
Consumed Apparent Energy L1
Consumed Apparent Energy L2
Consumed Apparent Energy L3
Total Apparent Energy consumed
Generated Active Energy L1
80
Table 19 (Continued): Modbus Memory Map: Energy variables (Table 2)�
Energies per Tariffs
Format Address
Uint [64] 604 - 605 - 606 - 607
Uint [64] 608 - 609 - 60A - 60B
Uint [64] 60C - 60D - 60E - 60F
Uint [64] 610 - 611 - 612 - 613
Uint [64] 614 - 615 - 616 - 617
Uint [64] 618 - 619 - 61A - 61B
Uint [64] 61C - 61D - 61E - 61F
Uint [64] 620 - 621 - 622 - 623
Uint [64] 624 - 625 - 626 - 627
Uint [64] 628 - 629 - 62A - 62B
Uint [64] 62C - 62D - 62E - 62F
Uint [64] 630 - 631 - 632 - 633
Uint [64] 634 - 635 - 636 - 637
Uint [64] 638 - 639 - 63A - 63B
Uint [64] 63C - 63D -63E - 63F
Uint [64] 640 - 641 - 642 - 643
Uint [64] 644 - 645 - 646 - 647
Uint [64] 648 - 649 - 64A - 64B
Uint [64] 64C - 64D - 64E - 64F
Uint [64] 650 - 651 - 652 - 653
Tariff 2
Format Address
Uint [64] 654 - 655 - 656 - 657
Uint [64] 658 - 659 - 65A - 65B
Uint [64] 65C - 65D - 65E - 65F
Uint [64] 660 - 661 - 662 - 663
Uint [64] 664 - 665 - 666 - 667
Uint [64] 668 - 669 - 66A - 66B
Uint [64] 66C - 66D - 66E - 66F
Uint [64] 670 - 671 - 672 - 673
Uint [64] 674 - 675 - 676 - 677
Uint [64] 678 - 679 - 67A - 67B
Uint [64] 67C - 67D - 67E - 67F
Uint [64] 680 - 681 - 682 - 683
Uint [64] 684 - 685 - 686 - 687
Uint [64] 688 - 689 - 68A - 68B
Uint [64] 68C - 68D - 68E - 68F
Uint [64] 690 - 691 - 692 - 693
Uint [64] 694 - 695 - 696 - 697
Uint [64] 698 - 699 - 69A - 69B
Uint [64] 69C - 69D - 69E - 69F
Uint [64] 6A0 - 6A1 - 6A2 - 6A3
Uint [64] 6A4 - 6A5 - 6A6 - 6A7
line-CVM-D32
Units
Wh
Wh
Wh
Wh
varhL
varhL
varhL
varhL
varhC
varhC
varhC
varhC
varh
varh
varh
varh
VAh
VAh
VAh
VAh
Units
Wh
Wh
Wh
Wh
varhL
varhL
varhL
varhL
varhC
varhC
varhC
varhC
varh
varh
varh
varh
VAh
VAh
VAh
VAh
Wh
